CT2525 Compact Tractor
CT2525 Compact Tractor
A Compact Tractor with a Deluxe cab for all-weather comfort, powered by an efficient 25 HP Stage V engine. Economy PTO 540E and a HST (Hydrostatic) Transmission will help you stay the most effective no matter the task. A wide portfolio of attachments tha can be connected with the Mid or Rear PTO.
CT2525 Overview
Bobcat Compact Tractors are a step up in productivity, versatility and reliability. Whatever your application, these machines help you get the job done efficiently thanks to their robust construction, smooth operation, flexible configuration, and full compatibility with a wide portfolio of attachments. And when it comes to maintenance, Bobcat's extensive service network gives you the support your business needs.
This Compact Tractor is also available with ROPS as model CT2025.
CT2525 Specifications
Compare
Key Specifications
CT2525 Compact Tractor
Engine power
24.5 hp
Lift capacity at 610 mm (24 in.) behind lift point
740 kg
Max PTO Power
19 hp
Transmission
HST, 3 range
Max speed forward
16.11 km/h
Drive Train
CT2525 Compact Tractor
Shuttle Type
Hydrostatic Drive
Max. Travelling Speed Reverse
11.28
Brake type
Wet disc type
Mechanical differential lock
Rear Std.
Max. Travelling Speed Forward
16.11
Front wheel drive system
Manual(MEC)
Turning radius(w/brake)
2450.00 MM
Hitch
CT2525 Compact Tractor
Top Link type
Turn-buckle
Lift rod type
Turn-buckle
Drawbar type
Bar(Clevis)
Check Link type (HST Transmission)
Telescope
Max. Drawbar vertical load
650.00 KG
Max. Trailer loading weight
3500.00 KG
@lift point (Horizontal position)
1101 (2427)
Lift capacity at 610 mm (24 in.) behind lift point
740.00 KG
Lift capacity at lift point
1030.00 KG
PTO
CT2525 Compact Tractor
Rear PTO type
Independent
Mid PTO speed
2000.00 RPM
Rear PTO
SAE 1-3/8, 6 Spline
Max PTO Power
19.00 HP
Rear PTO speed
540/540E RPM
Capacity (Other)
CT2525 Compact Tractor
Support of front axle
6.00 L
Transmission case
22.00 L
Engine crankcase(included filter)
5.80 L
Tires
CT2525 Compact Tractor
Industrial Tires
Front: 25x8.5-14 R4 / Rear: 15-19.5 R4
Agriculture Tires
Front: 7-16 R1 / Rear: 11.4-24 R1
Turf tires
Front: 27x8.5-15 R3 / Rear: 41x14.0-20 R3
Hydraulic System
CT2525 Compact Tractor
Power steering pump
15.60
Total hydraulic flow
39.60
Implement Pump
24.00
No.of Std. remote valve's ports (Rear)
Std. (4 port)
Drive System
CT2525 Compact Tractor
Transmission
HST, 3 range
Fluid Capacities
CT2525 Compact Tractor
Fuel tank
34.00 L
Fluid Specifications
CT2525 Compact Tractor
Coolant
3.30
Controls
CT2525 Compact Tractor
Steering
Hydrostatic Power Steering
Electrical
CT2525 Compact Tractor
Alternator
12V/75A
Dimensions
CT2525 Compact Tractor
Overall Length with Ballast Weights
3487.00 MM
Front Overhang
546.00 MM
Front Overhang with Ballast Support
668.00 MM
Wheelbase
1670.00 MM
Rear Overhang to Lower Link
812.00 MM
Distance from the center of Rear Axle to Coupling Point
626.00 MM
Overall height
2372.00 MM
Front track width
1126.00 MM
Rear track width
1102.00 MM
Ground Clearance under the Rear Axle (Hitch Frame)
338.00 MM
Overall Width
1385.00 MM
Weight with CABIN
1601.00 KG
Engine
CT2525 Compact Tractor
Fuel
Diesel
Displacement
1.60 L
Air Cleaner
Dry type, replaceable
Max Torque
84.00
Gross Power (ECE-R120)
24.50 HP
Net Power
23.00 HP
Rated revolution
2400.00 RPM
Engine type
3 cylinder, water cooled, 4 cycle, Indirect Injection (IDI)
Standard Features
CT2525 Compact Tractor
4 Wheel Drive
yes
Tilt Steering
yes
HST Cruise
yes
HST RPM Link
yes
Cabin w/HVAC, Sunvisor, Front/Rear work lights
yes
Rear PTO, Independent
yes
PTO Cover
yes
Stationary PTO
yes
Auto PTO
yes
Joystick Lever
yes
Front Hitch
yes
7 Pin Socket
yes
12V Aux
yes
Beacon Ready Wiring
yes
Engine Hood, one piece
yes
Textile Suspension Seat, w/retractable seat belt
yes
Battery
yes
Horn
yes
Rear View Mirror
yes
Cup holder
yes
OPC
yes
Floor mat
yes
Toolbox
yes
