S70
Skid-Steer Loader

S70
Skid-Steer Loader

The S70 is the smallest compact loader in the Bobcat lineup. It’s small in stature, but a giant in performance. Behind the controls, you’ll efficiently complete demanding work where other machines struggle or can’t go.

  • Efficient Tier 4 engine
  • Leading attachment versatility
  • Superior performance in a small package
  • Bob-Tach mounting system for easy attachment changes

Starting at $28,160 USD*

Pay as low as 0% for up to 48 months* or choose a $1,500 USD*/$2,000 CAD* rebate on Bobcat S70 skid-steer loaders.

S70 Overview

  • The S70 is compatible with a variety of attachments including a snowblower, sweeper, nitrogen breaker, trencher, snow blade, soil conditioner and much more.
  • At just three feet wide with a standard bucket, the S70 is ideal for challenging tasks in confined spaces.

S70 Specs & Compare

Compare
Units

S70 Key Specifications

Horsepower
23.5 hp
Rated Operating Capacity (ISO)
760 lb
Operating Weight
2892 lb
Auxiliary Std Flow
9.8 gal/min
Joystick Control
Not Applicable

S70 Key Specifications

Horsepower
23.5 hp
Rated Operating Capacity (ISO)
760 lb
Operating Weight
2892 lb
Auxiliary Std Flow
9.8 gal/min
Joystick Control
Not Applicable

Engine

Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Fuel
Diesel
Horsepower
23.5 hp
Turbocharged Engine
no

Performance

Rated Operating Capacity (ISO)
760 lb
Tipping Load
1520 lb
Operating Weight
2892 lb
Travel Speed
6.3 mph

Capacities

Fuel Tank
6.5 gal

Hydraulic System

Auxiliary Std Flow
9.8 gal/min

Dimension

Length
75.6 in
Length without Attachment
75.6 in
Length with Standard Bucket
97.3 in
Width
35.5 in
Width (with bucket)
36 in
Height with Operator Cab
71.4 in
Height to Bucket Hinge Pin
94.5 in
Reach @ Maximum Height
15.8 in
Turning Radius
58.7 in

Features

Joystick Control
Not Applicable
Air Conditioning
Not Applicable
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
Sound Option
Optional
Cab Heater
Optional
Operating Lights
Standard
Parking Brake
Standard
Radio
Not Applicable
Rear Window
Standard
Top Window
Optional
Lift-Arm Support
Standard
Seat Belt
Standard
Suspension Seat
Standard
Two Speed Travel
Not Applicable
Deluxe Instrumentation
Not Applicable
Engine Shutdown
Not Applicable
High Flow Option
Not Applicable
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Not Applicable
Ride Control
Not Applicable
Rear Hydraulics
Not Applicable
Horn
Standard

S70 Features & Benefits

S70 Attachments

View All Attachments
  • S70 Bobcat S70 Skid-Steer Loader Knockout Image
    Narrow Width

    S70

    Horsepower
    23.5 hp
    Rated Operating Capacity (ISO)
    760 lb
    Operating Weight
    2892 lb

  • S450 Bobcat S450 Skid-Steer Loader Knockout Image

    S450

    Horsepower
    49 hp
    Rated Operating Capacity (ISO)
    1370 lb
    Operating Weight
    5370 lb

  • S510 Bobcat S510 Skid-Steer Loader Knockout Image On White Background

    S510

    Horsepower
    55 hp
    Rated Operating Capacity (ISO)
    1876 lb
    Operating Weight
    6208 lb

  • S590 Studio Image Of Bobcat S590 Skid-Steer Loader With Bucket Attachment

    S590

    Horsepower
    68 hp
    Rated Operating Capacity (ISO)
    2000 lb
    Operating Weight
    6765 lb
